REGULATOR - COMMERCIAL LOW-PRESSURE - 1" FNPT

Fisher CS200 Series direct-operated, spring-loaded regulators provide pressure-reducing applications for commercial and light industrial installations. Options include numerous body sizes, outlet pressure settings, and orifice sizes. CS200 offers ease of maintenance and installation with its full 360-degrees of rotation of the actuator via the union ring connection between the body and casing.

Features:

• Wide Range of NPT Body Sizes and End Connections
• Easy to Install and Maintain
• Only Standard Tools Required for Pressure Adjustment and Orifice Removal
• Fixed Factor Accuracy
• Application Flexibility Including Internal Relief, Non-Relieving, and Secondary Seat Protection
• Secondary Seat Protection Provides a Secondary Seating and Disk Surface in the Event That Damage to the Primary Disk or Orifice Seat or Debris in the Flow Path Inhibit Lockup

Specifications:

• 1" FNPT x 1" FNPT
• Maximum Operating Inlet Pressure: 40 psig
• Outlet Pressure Range:  1-2 psig; Setpoint: 2 psig
• Capacity:  4,780,000 BTU/hr
