ME571H HIGH FLOW HOSE END FILL ADAPTER

ID: ME571H

MEC ME571H HOSE END VALVE

1-3/4" FILLER VALVE FEMALE ACME CONNECTION

1-3/4" HOSE END MALE ACME CONNECTION

STANDARD HANDLE

BRASS CONSTRUCTION

ALLOWS OPERATION OF HOSE END TO SWIVEL

NO VENT VALVE

30% MORE FLOW - 86GPM @30PSI PRESSURE DIFFERENTIAL

Details

These adapters are intended for use on LP-gas delivery truck hose outlets. Features the Industry's Highest Flow Rate for fast delivery while providing the ability to remove the hose end filler valve in the event that the tank fill valve fails to close. During a tank filler valve failure, the integral check valve prevents loss of product. The ME571 is specifically designed to work in conjunction with the ME800 series of minimal loss hose end valves and will allow normal swivel operation of the hose end valve fill nozzle.

Features:

Industry's Highest Flow Rates - 86 GPM LPG @ 30 PSI pressure differential (based on hose end adapter only)
Short overall profile allows valve to remain inside tank dome
Floating Internal seat design allows product to swivel freely when installed on hose end valve
Single piece brass body design for maximum product life
Scalloped body for comfortable and secure grip
