ME571 HOSE END FILL ADAPTER

ID: ME571

MEC ME571 HOSE END VALVE

1-3/4" FILLER VALVE FEMALE ACME CONNECTION

1-3/4" HOSE END MALE ACME CONNECTION

STANDARD HANDLE

BRASS CONSTRUCTION

ALLOWS OPERATION OF HOSE END TO SWIVEL

NO VENT VALVE

Details

These adapters are intended to be attached to the LP-gas delivery truck hose outlet. Features minimal flow restriction for fast delivery and provides the ability to remove the hose end filler valve in the event that the tank fill valve fails to close. During a tank filler valve failure, the intergral check valve prevents loss of product. The ME571 is specifically designed to work in conjunction with the ME800 series of minimal loss hose end valves and will allow normal swivel operation of the hose end valve fill nozzle.

Features:

Short overall profile allows valve to remain inside tank dome
Floating Internal seat design allows product to swivel freely when installed on hose end valve
Single piece brass body design for maximum product life
Coarse diamond knurl allows operator the best possible grip
